Broadway’s Ozone Prep Unit produces ozone (O3), which is a highly reactive gas. This gas is injected into the water holding tanks to kill all forms of bacteria that are present in the water. Once injected into the water, the ozone kills any bacteria it comes in contact with and causes an oxygen byproduct reaction with also helps the odor problem. This unit comes in different sizes depending on the needs your system may have. The system is designed and programmed to run separate from the car wash and reclaim system. Good maintenance and good equipment will leave you with great odor free washing water.



Features

• Comes with programmable logic control for easy operation.
• Hand/Off/Auto Switch with alarm light for easy use.
• Equipped with a 1.5HP suction motor.
• Comprised of water safe material.
• UL listed.
• Electric Supply: 208V 20 Amp 3Phase
• Electric Supply: 120V 20 Amp
• Space Requirements: 24”L x 24”W x 63”H



Technical

Dimensions (L x W x H)	36 x 36 x 60	inch
Power supply	3 phase 20 amp	V/Hz/A
Weight approx.	175	lbs
